Type

L

φI.C

S

φ d

r

DCGT070202ER-U

7.8

6.35

2.38

2.8

0.2

DCGT070204ER-U

7.8

6.35

2.38

2.8

0.4

DCGT070208ER-U

7.8

6.35

2.38

2.8

0.8

DCGT11T302ER-U

11.6

9.525

3.97

4.4

0.2

DCGT11T304ER-U

11.6

9.525

3.97

4.4

0.4

DCGT11T308ER-U

11.6

9.525

3.97

4.4

0.8

DCGT11T312ER-U

11.6

9.525

3.97

4.4

1.2

DCGT070202L-F

7.8

6.35

2.38

2.8

0.2

DCGT070204L-F

7.8

6.35

2.38

2.8

0.4

DCGT070208L-F

7.8

6.35

2.38

2.8

0.8

DCGT11T302L-F

11.6

9.525

3.97

4.4

0.2

DCGT11T304L-F

11.6

9.525

3.97

4.4

0.4

DCGT11T308L-F

11.6

9.525

3.97

4.4

0.8

DCGT11T312L-F

11.6

9.525

3.97

4.4

1.2

DCGT070202-AK

7.8

6.35

2.38

2.8

0.2

DCGT070204-AK

7.8

6.35

2.38

2.8

0.4

DCGT070208-AK

7.8

6.35

2.38

2.8

0.8

DCGT11T302-AK

11.6

9.525

3.97

4.4

0.2

DCGT11T304-AK

11.6

9.525

3.97

4.4

0.4

DCGT11T308-AK

11.6

9.525

3.97

4.4

0.8

DCGT11T312-AK

11.6

9.525

3.97

4.4

1.2
